TC78B004AFTG - Brushless Motor Controller

Toshiba

📥 Download Datasheet

TC78B004AFTG Datasheet Preview — Preview of TC78B004AFTG PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	TC78B004AFTG
Manufacturer	Toshiba
File Size	1.86 MB
Description	Brushless Motor Controller
Datasheet	TC78B004AFTG-Toshiba.pdf

TC78B004AFTG Product details

Description

Pin No.

Features

Sine-wave PWM driving system.
2-phase modulation system with low switching loss.
Built-in Dead time function.
External clock input.
FLL + PLL speed control circuit.
READY circuit output.
Built-in FG amplifier.
Built-in Auto lead angle correction function.
Built-in CW/Stop (Standby) / CCW / Brake functions.
Built-in Over current limitation function.
Built-in Lock protection function Note: This product has a MOS structure and is sensitive to.
