TA8025F, PICK UP SENSOR INTERFACE IC

TA8025P/F Pin No.

1 2 3 4 5 6 7 8 Symbol IN REF CT GND A.G OUT N.C VCC Description Input pin for a signal from sensor.

VTH setting pin.

The VTH value can be set according to divide the input signal with resistors.

This pin hold the peak value for input signal of REF pin.

Grounded.

Grounded pin f

TA8025F Features

* Input frequency : DC~50kHz

* Input voltage VTH : 0V ←→ Vpeak×K

* Small package : DIP

* 8pin (TA8025P) : SOP

* 8pin (TA8025F)

* Separate GND line for output and logic control sections TA8025P TA8025F Weight DIP8-P-300-2.54A : 0.45 g (typ.) SOP8-P-225-1.27 : 0.0
