C2073A Silicon NPN Transistor

C2073A Description

2SC2073A TOSHIBA Transistor Silicon NPN Triple Diffused Type (PCT Process) 2SC2073A Power Amplifier Applications Vertical Output Applications Unit: .

C2073A Applications

* Vertical Output Applications Unit: mm Absolute Maximum Ratings (Ta = 25°C) Characteristic Symbol Rating Unit Collector-base voltage VCBO 150 V Collector-emitter voltage VCEO 150 V Emitter-base voltage VEBO 5 V Collector current IC 1.5 A Base current IB 0.5 A Collector power dissipat

📥 Download Datasheet

Preview of C2073A PDF
datasheet Preview Page 2 datasheet Preview Page 3
