TP4066 1A Standalone Linear Li-lon Battery Charger

TP4066 Description

NanJing Top Power ASIC Corp.TP4066 TP4066 1A Standalone Linear Li-lon Battery Charger with Thermal Regulation in ESOP8 / DFN2 *2-8 DESCRIPTIO.
The TP4066 is a complete constant-current/constant-voltage linear charger for single cell lithium-ion batteries, with battery reverse connect protecti.

TP4066 Features

* include supply voltage self adaptive, current monitor, under voltage lockout, automatic recharge and two status pin to indicate charge termination and the presence of an input voltage. FEATURES
* Lithium-ion batteries Reverse battery protection
* Power adaptive
* Programmable

TP4066 Applications

* Furthermore, the TP4066 can work within USB and wall adapter. No blocking diode is required due to the internal PMOSFET architecture and have prevent to negative Charge Current Circuit. Thermal feedback regulates the charge current to limit the die temperature during high power operation or high am

📥 Download Datasheet

Preview of TP4066 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
TP4066
Manufacturer
Top Power
File Size
735.21 KB
Datasheet
TP4066-TopPower.pdf
Description
1A Standalone Linear Li-lon Battery Charger
