LTC455DU - Communication Ceramic Chip Filters

Download the LTC455DU datasheet PDF. This datasheet also covers the LTC455BU variant, as both devices belong to the same communication ceramic chip filters family and are provided as variant models within a single manufacturer datasheet.

Features

  • :.
  • LTM 455 EU Dimensions: (6.5 × 6.5 × 6.2 mm).
  • LTM 455 EW Dimensions: (6.5 × 9.5 × 6.2 mm).
  • Center Frequency: 455kHz (450kHz is also available).
  • Input / Output Impedance: 1000Ω ~ 2000Ω.
  • Insertion Loss (dB) max: 4db, 6db.
  • Pass Band Ripple (dB) max: 2db. Token communication ceramic filter is Murata CFUM/WM 455/450 compatible. Token ceramic filters for communication LTM 455/450 U/W series are miniaturized versions of the Murata CFU/CFWS lines. These.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (LTC455BU-Token.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number LTC455DU
Manufacturer Token
File Size 459.54 KB
Description Communication Ceramic Chip Filters
Datasheet download datasheet LTC455DU Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
LTC455 Ceramic Filter AiT Components
LTC455 CERAMIC FILTER Transko
LTC4555 SIM Power Supply and Level Translator Linear Technology
LTC4556 Smart Card Interface Linear Technology
LTC4557 Dual SIM/Smart Card Power Supply/Interface Linear Technology

Other Datasheets by Token

Part Number Description
LTC455DW Communication Ceramic Chip Filters
LTC455BU Communication Ceramic Chip Filters
LTC455BW Communication Ceramic Chip Filters
LTC455CU Communication Ceramic Chip Filters
LTC455CW Communication Ceramic Chip Filters

Full PDF Text Transcription

Click to expand full text
Version: January 12, 2017 (LTM 455/450 U/W) Communication Ceramic Filters Web: www.token.com.tw Email: rfq@token.com.tw Token Electronics Industry Co., Ltd. Taiwan: No.137, Sec. 1, Zhongxing Rd., Wugu District, New Taipei City, Taiwan, R.O.C. 24872 Tel: +886 2981 0109 Fax: +886 2988 7487 China: 12F, Zhong Xing Industry Bld., Chuang Ye Road, Nan Shan District, Shen Zhen City, Guang Dong, China 518054 Tel: +86 755 26055363; Fax: +86 755 26055365  Product Introduction Introduction (LTM 455/450 U/W) Features :  LTM 455 EU Dimensions: (6.5 × 6.5 × 6.2 mm).  LTM 455 EW Dimensions: (6.5 × 9.5 × 6.2 mm).  Center Frequency: 455kHz (450kHz is also available).  Input / Output Impedance: 1000Ω ~ 2000Ω.  Insertion Loss (dB) max: 4db, 6db.  Pass Band Ripple (dB) max: 2db.
