TL1013 - 25W LinearPA GaAs module

Description

This class A GaAs module is designed for both military and commercial applications.

It is capable of supporting any signal type and modulation format, including but not limited to 3-4G telecom, WLAN, OFDM, DVB, and CW/AM/FM.

Features

Over / Under / Reverse Voltage Protection Forward Power Measurement Reflected Power Measurement High Speed On/Off Control Temperature Output Optional Heatsink Specifications subject to change without notice. Typical performance at +12VDC at +25oC in a 50Ω system RF /.

TRIAD

📥 Download Datasheet

Datasheet Details

Part number	TL1013
Manufacturer	TRIAD
File Size	403.94 KB
Description	25W LinearPA GaAs module
Datasheet	TL1013 Datasheet
