K170 - LOW VOLTAGE OPERATIONAL AMPLIFIER

Description

The TK17010 is a single-supply operational amplifier capable of operating from a very low and very wide supply voltage range (VCC = 1.0 to 7 V).

With its rail-to-rail structures, the input signal circuit can accept a very wide input voltage range (VIN = 0 to 1.4 VP-P).

Features

  • s Very Low and Wide Operating Voltage Range (VOP = 1.0 to 7 V) s Very Wide Input Signal Voltage Range (VIN = 0 V to 1.4 VP-P) s Very Large Output Signal (VOUT(MAX) = 1.4 VP-P) s Very Large Output (Source) Current (IOUT(MAX) = 660 µA) s Very Small SOT23L-6 Package.

📥 Download Datasheet

Datasheet Details

Part number K170
Manufacturer TOKO Inc
File Size 47.88 KB
Description LOW VOLTAGE OPERATIONAL AMPLIFIER
Datasheet download datasheet K170 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
K170 FET/ Silicon N Channel Junction Type(for Low Noise Audio Amplifier) Toshiba
K170 Low EMI Clock Generator Integrated Circuit Systems
K1700A 5V Temperature Compensated Voltage Controlled Crystal Oscillators Champion
K1713 Two-color detector Hamamatsu
K1713-01 Two-color detector Hamamatsu

Other Datasheets by TOKO Inc

Part Number Description

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
TK17010 LOW VOLTAGE OPERATIONAL AMPLIFIER FEATURES s Very Low and Wide Operating Voltage Range (VOP = 1.0 to 7 V) s Very Wide Input Signal Voltage Range (VIN = 0 V to 1.4 VP-P) s Very Large Output Signal (VOUT(MAX) = 1.4 VP-P) s Very Large Output (Source) Current (IOUT(MAX) = 660 µA) s Very Small SOT23L-6 Package APPLICATIONS s Battery-Powered Equipment DESCRIPTION The TK17010 is a single-supply operational amplifier capable of operating from a very low and very wide supply voltage range (VCC = 1.0 to 7 V). With its rail-to-rail structures, the input signal circuit can accept a very wide input voltage range (VIN = 0 to 1.4 VP-P). The TK17010 can also provide a very large output signal (VOUT(MAX) = 1.4 VP-P) while operating from a single 1.5 volt supply.
