ADSL Line Transformer Through Hole Magnetics
ADSL Transformer RoHS compliance product EN60950 Basic Insulation Compliant-250Vrms Operating temperature range:-400C to +850C Electrical Specifications @ 25℃
Turns Ratio Part Number 1-5：10-6 （2-4，7-9 short） TDA002 1.6: 1±2％ OCL @10KHz 100mV 1-5 (2-4 short) 410uH ±5％ LL @100KHz 100mV 1-5 (2-4，6-7-9-10) 10 uH max 1-4 DCR(Ω max) THD @30KHz 4.5 V 2-5 9-6 10-7 Hi-Pot
1.0
1.0
0.40
0.35
-80dB MAX.
6000VDC/1S/1mA
Mechanical
14 MAX. 6 10 14.5 MAX.
. ?0 9
Schematics
6 10 10
YYWW
10
TDA002
5 1
2.5 5 1
1
4 2 5
10 7 9 6
PIN3
13.5 MAX.
0.6±0.1 2.5±0.2
3.5±0.5
10±0.5
Dimension:Inches/mm Unless otherwise specified,tolerances:xx.x0±0.25(mm) 0.xx±0.05(mm) Data sheet subject to change without notice Dong Guan TNK Industry CO.,LTD Add: No.
TDA002 Datasheet
