SMF22A, SMF5.0A, 200W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

SMF5.0A~SMF190CA 200W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR .

datasheet Preview Page 1 from Datasheet4u.com

SMF5.0A-TIPTEK.pdf

SMF22A Datasheet Preview — This datasheet PDF includes multiple part numbers: SMF22A, SMF5.0A. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

SMF22A, SMF5.0A

Manufacturer:

TIPTEK

File Size:

316.02 KB

Description:

200W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Note:

This datasheet PDF includes multiple part numbers: SMF22A, SMF5.0A.
Please refer to the document for exact specifications by model.

Features

* Glass passivated chip
* 200 W peak pulse power capability witha 10/1000 μs waveform, repetitive rate(duty cycle):0.01 %
* Low leakage
* Uni and Bidirectional unit.
* Excellent clamping capability
* Very fast response time MECHANICAL DATA
* Case: Molded plastic
* Epo
