D5RB942M5E1CF - SAW Duplexers

Product Overview

TAIYO YUDEN

Part number	D5RB942M5E1CF
Manufacturer	TAIYO YUDEN
File Size	464.51 KB
Description	SAW Duplexers
Datasheet	D5RB942M5E1CF Datasheet
Additional preview pages of the D5RB942M5E1CF datasheet.

Item Summary SAW, Duplexer, 1.8x1.4x0.5mm Band 8 Lifecycle Stage Mass Production Standard packaging quantity (minimum) Taping Embossed 3000 , 15000pcs Products characteristics table System Type Function band Insertion Loss (typ) (Tx-ANT/ANT-Rx) Isolation (typ) Operating Temp. Range RoHS2 Compliance (10 subst. ) REACH Compliance (168 subst. ) Soldering W-CDMA / LTE SAW Duplexer Band 8 1.5/1.9 dB 56/51 dB -20 to +85 ℃ Yes Yes Reflow External Dimensions Dimension L 1.8 ±0.10 mm Dimension W 1.4.
