Description
VR VRRM IF(AV)
IFSM PD
RthJA TJ, TSTG
Pinout Figure
Marking Code
Reverse Voltage
Peak Reverse Voltage
Average Forward Rectified Current Non-repetitive Peak Forward Surge Current
Power Dissipation
Thermal Resistance from Junction to Ambient Air Operating Junction and Storage Temperature Range
BAS21A 5
21A
BAS21C 4
21C 250 250 0.2
4 250 357
-55 to +150
BAS21S 3
21S
Unit
Conditions
V V A TA=25° C A t=1.0µs mW ° C/W
°C
TAIT.
Features
- High reverse breakdown voltage.
- Fast switching speed.
- Low reverse leakage current.
- Surface mount package ideally suited for automatic insertion.
- Galvanically isolated dual configurations to save board space.
- RoHS compliant
SOT-23
Mechanical Data
Case: Terminals:
Weight:
SOT-23, Plastic Case Solderable per MIL-STD-750, Method 2026 Approx. 0.008 gram
Maximum Ratings (T Ambient=25ºC unless noted otherwise)
Symbol.
