MA700 - AXIAL LEADED FAST SWITCHING DIODE

Product Overview

Sunmate

📥 Download Datasheet

MA700 AXIAL LEADED FAST SWITCHING DIODE by Sunmate - Datasheet Preview — Datasheet preview – MA700

Datasheet Details

Part number	MA700
Manufacturer	Sunmate
File Size	1.39 MB
Description	AXIAL LEADED FAST SWITCHING DIODE
Datasheet	MA700 Datasheet
Additional preview pages of the MA700 datasheet.

Product details

Features

! Low forward voltage VF ! Small temperature coefficent of forward characterisble ! Small reverse current IR ! High-densitty mounting ( 5mm pich insertion) is possible Mechanical Data ! Case: DO-35, glass case ! Polarity: Color band denotes cathode ! Weight: 0.004 ounces, 0.13 grams MA700-MA700A AXIAL LEADED FAST.
