SPCA711A Digital Video Encoder

SPCA711A Description

SPCA711A DIGITAL VIDEO ENCODER FOR VIDEOCD GENERAL .
The SPCA711A is designed specifically for VideoCD, video games and other digital video systems, which require the conversion of digital YCrCb (MPEG) d.

SPCA711A Features

* ! 8-bit 4:2:2 YCrCb inputs for glue-less interface to MPEG decoders ! NTSC/PAL/PAL-M/PAL-Nc composite video outputs BLOCK DIAGRAM VBIAS VREFOUT FSADJUST CLK ! CVBS or S-video outputs ! 3.3 V supply voltage ! CCIR 601 operation ! 2x over sampling simplifies external filtering ! 9-bit DACs ! Master

SPCA711A Applications

* ! VideoCD ! Karaoke/video games ! Digital Video Disk (DVD) ! Digital VCR ! Digital set top box                                                          www. DataSheet4U. com HSYNC
* SPCA711A PINOUT a

📥 Download Datasheet

Preview of SPCA711A PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
SPCA711A
Manufacturer
SunPlus
File Size
150.47 KB
Datasheet
SPCA711A_SunPlus.pdf
Description
Digital Video Encoder
