NZ9F10 Features
* Standard Zener Breakdown Voltage Range
* 2.4 V to 18 V
* Steady State Power Rating of 200 mW
* Small Body Outline Dimensions: 0.039″ x 0.024″ (1.00 mm x 0.60 mm)
* Low Body Height: 0.016 ″ (0.40 mm)
* ESD Rating of Class 3 (>16 kV) per Human Body Mode
Datasheet Details
NZ9F10, NZ9F2V4S
SunMate
326.77 KB
Surface mount silicon zener diodes.
This datasheet PDF includes multiple part numbers: NZ9F10, NZ9F2V4S.
Please refer to the document for exact specifications by model.
