CXA1100P, CXA - DOLBY B TYPE NOISE REDUCTION SYSTEM

Sony Corporation

📥 Download Datasheet

CXA1100P Datasheet Preview — This datasheet PDF includes multiple part numbers: CXA1100P, CXA. Please refer to the document for exact specifications by model.

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	CXA1100P, CXA
Manufacturer	Sony Corporation
File Size	473.58 KB
Description	DOLBY B TYPE NOISE REDUCTION SYSTEM
Datasheet	CXA-1100.pdf
Note	This datasheet PDF includes multiple part numbers: CXA1100P, CXA. Please refer to the document for exact specifications by model.

CXA1100P Product details

Description

CXA1100, CXA1101, CXA1102 and CXA1163 are ICs including two separate Dolby B type noise reduction processors.

Features

Minimum number of external components.
NR ON/OFF and REC/PB switchs included.
Small package (DIP16, SOP16) ~ 5.5mA, Typ. ).
Small supply current (.
Dual channel processors in one chip Absolute Maximum Ratings (Ta = 25°C).
Supply voltage VCC 17 V.
Operating temperature Topr.
30 to +85 °C.
Storage temperature Tstg.
55 to +150 °C.
Allowable power dissipation PD DIP16 (A1100P/A1101P/A1102P/A1163.
