SLM346 - 2.5A Opto-Compatible Single Channel Isolated Gate Driver

Sillumin

The SLM346 by Sillumin is a 2.5A Opto-Compatible Single Channel Isolated Gate Driver. Below is the official datasheet preview.

📥 Download Datasheet

SLM346 2.5A Opto-Compatible Single Channel Isolated Gate Driver by Sillumin - Datasheet Preview — Official preview page of the **SLM346** 2.5A Opto-Compatible Single Channel Isolated Gate Driver datasheet (Sillumin).

Datasheet Details

Part number	SLM346
Manufacturer	Sillumin
File Size	327.14 KB
Description	2.5A Opto-Compatible Single Channel Isolated Gate Driver
Datasheet	SLM346-Sillumin.pdf
Additional preview pages of the SLM346 datasheet.

SLM346 Product details

Description

The SLM346 is an opto-compatible, single channel, isolated gate driver for IGBTs, MOSFETs with 2.5A source and 2.5A sink peak output current and 5kVRMS reinforced isolation rating.

Features

and characteristics bring significant performance and reliability upgrades over standard optocoupler based gate drivers while maintaining pin-to-pin compatibility in both schematic and layout design. Performance highlights include high common mode transient immunity (CMTI), low propagation delay, and small pulse width distortion. The input stage is an emulated diode which means long term reliability and excellent aging characteristics compared to traditional LEDs. It is offered in a stretched SO.
