SLG7NT4081
PWROK GENERATOR AND STARTUP LATCHING CIRCUIT
General Description
Silego SLG7NT4081 is a low power and small form device. The SoC is housed in a 2.5mm x 2.5mm TDFN package which is optimal for using with small devices.
Features
• Low Power Consumption • 3.3V Supply Voltage • RoHS Compliant / Halogen-Free • Pb-Free TDFN-12 Package
Pin Configuration
SLG7NT4081
VDD BC_ACOK_DSW V3.3A_DSW_PWRGD VBAT_MON_DPWROK
BC_ACOK PCH_DPWROK_R
1 2 3 4 5 6
TDFN-12 TOP VIEW
Output Summary
• 2 Outputs – Push Pull • 2 Outputs – Open Drain
12 VR_ALW_ENABLE 11 SMC_SHUTDOWN 10 STARTUP_LATCH_SET 9 SMC_ONOFF_N 8 PS_ON_SW_N 7 GND
Thermal Pad connected to GND
Silego Technology, Inc. SLG7NT4081_DS_r103 SLG7NT4081_GP_r005
Rev 1.
SLG7NT4081 Datasheet
