PEF2023 - ISDN DC Converter Circuit IDCC

Name: PEF2023
SKU: PEF2023-39560

Siemens Semiconductor Group

The PEF2023 by Siemens Semiconductor Group is a ISDN DC Converter Circuit IDCC. Below is the official datasheet preview.

Datasheet Details

Part number	PEF2023
Manufacturer	Siemens Semiconductor Group
File Size	171.15 KB
Description	ISDN DC Converter Circuit IDCC
Datasheet	PEF2023_SiemensSemiconductorGroup.pdf
Additional preview pages of the PEF2023 datasheet.

br> . . . . .

Switched Mode DC/DC Converter ITU ISDN Compatible Low Power Dissipation Supply Voltage Range 0: 8V to 16V Supply Voltage Range 1: 12V to 80V Supply Voltage Range 2: 22V to 90V (pin striping selects between range 1 and range 2) Supply Voltage Range 3, with shifting by an external zener diode: UZD+8V to UZD+90V (minimum zener voltage UZD = 14V) Programmable Overcurrent Protection Soft Start Power Housekeeping Input Input.
