SHINDENGEN
Switching Power Transistor
LSV Series
2SC4151
(TP15S4)
15A NPN
OUTLINE DIMENSIONS
Case : ITO-220 Unit : mm
RATINGS
•œAbsolute Maximum Ratings Item Symbol Conditions Ratings Unit Storage TemperatureTstg -55•`150 •Ž Junction Temperature Tj 150 •Ž Collector to Base Voltage V 60 V CBO Collector to Emitter Voltage V 40 V CEO Emitter to Base Voltage V 7 V EBO Collector Current DC I 15 A C Collector Current Peak I 30 A CP Base Current DC I 2 A B Base Current Peak I 3 A BP Total Transistor Dissipation P 30 W T Tc = 25•Ž Dielectric Strength Vdis Terminal to case, AC 12mitute kV Mounting Torque TOR (Recommended torque 0.5 : 0.3N¥m•j N¥m •œElectrical Characteristics (Tc=25•Ž) Conditions Ratings Item Symbol Unit Collector to EmitterV Sustaining (sus)I = 0.
