2SA1598, Switching Power Transistor

SHINDENGEN Switching Power Transistor LSV Series 2SA1598 (TP7T4) -7A PNP OUTLINE DIMENSIONS Case : ITO-220 Unit : mm RATINGS œAbsolute Maximum Ratings Item Symbol Conditions Ratings Unit Storage TemperatureTstg -55 `150 Ž Junction Temperature Tj 150 Ž Collector to Base Voltage V -60 V CBO Collector to Emitter Voltage V -40 V CEO Emitter to Base Voltage V -7 V EBO Collector Current DC I -7 A C Collector Current Peak I -14 A CP Base Current DC I -1.5 A B Base
