PQ1CZ21H2ZP - Boot Strap System Chopper Regulator

Name: PQ1CZ21H2ZP
SKU: PQ1CZ21H2ZP-499434

Sharp

The PQ1CZ21H2ZP by Sharp is a Boot Strap System Chopper Regulator. Below is the official datasheet preview.

Datasheet Details

Part number	PQ1CZ21H2ZP
Manufacturer	Sharp
File Size	106.96 KB
Description	Boot Strap System Chopper Regulator
Datasheet	PQ1CZ21H2ZP_Sharp.pdf
Additional preview pages of the PQ1CZ21H2ZP datasheet.

Boot Strap System Chopper Regulator Outline Dimensions 5.2 8 7 6 5 1 2 3 4 5 6 7 8 VIN VB NC ON/OFF Vadj COM COM VO [PQ1CX12H2ZP] 4.4 Expansion of Chopper Regulator System Model No. Efficiency SW current(MAX) Input voltage Package Outline dimension General purpose type Boot strap system PQ1CY1032ZP/ZZ PQ1CX12H2ZP TYP 82% (12V → 5V,2A) TYP 87% (12V → 5V,2A) TYP 75% (5V → 3.3V,2A) TYP 85% (5V → 3.3V,2A) 3.5 A 2.5 A High efficiency 4.5 to 40 V Compact package 4.5 to 20 V TO-263type 5 -pin SOP8.
