PC81410NSZ
Features
1. Low input current type (IF=0.5m A) 2. High resistance to noise due to high mon rejection voltage (CMR:MIN. 10k V/µs) 3. AC input type 4. pact dual-in line package 5. Isolation voltage (Viso:5k Vrms) 6. Recognized by UL, file No. E64380 s Applications
1. Programmable controllers 2. Facsimiles 3. Telephones s Rank Table
Model No. Rank mark
PC81410NSZ A or no mark
PC81411NSZ
Ic (m A) 0.25 to 2.0 0.5 to 1.5
Conditions IF=±0.5m A
VCE=5V Ta=25°C s Absolute Maximum Ratings
(Ta=25°C)
Parameter
Symbol Rating Unit
Forward current IF
±10 m A
Input
- 1 Peak forward current IFM Power dissipation P
±200 15 m A m W
Collector-emitter voltage VCEO
Output Emitter-collector voltage VECO
Collector current IC
50 m A
Collector power dissipation PC
150 m W
Total power dissipation Ptot
170 m W
Operating temperature
Storage temperature
- 2 Isolation voltage
- 3 Soldering...
