PC814 - AC Input Photocoupler

Sharp Electrionic Components

📥 Download Datasheet

PC814 Datasheet Preview — Preview of PC814 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	PC814
Manufacturer	Sharp Electrionic Components
File Size	67.80 KB
Description	AC Input Photocoupler
Datasheet	PC814_SharpElectrionicComponents.pdf

PC814 Product details

Features

1. AC input 2. High isolation voltage between input and output ( V : 5 000Vrms ) 3. Compact dual-in-line package PC814 (1-channel type ) PC824 (2-channel type ) PC844 (4-channel type ) 4. Current transfer ratio CTR : MIN. 20% at IF = ± 1mA, VCE = 5V 5. Recognized by UL, file No. E64380 s.
