STR-W605xS, STRW605xS Current Mode Control PWM Regulator IC

STR-W605xS Description

STR-W605xS Current Mode Control PWM Regulator IC For Switching Power Supplies .
The STR-W605xS series are power ICs for switching power supplies, incorporating a power MOSFET and a current mode PWM controller IC.

STR-W605xS Features

* ▪ TO-220F power package with 30 to 90 W power output ▪ Current Mode PWM control ▪ Built-in Random Switching function, reducing EMI noise, and simplifying EMI filters, and therefore reducing cost ▪ Built-in Slope Compensation function, avoiding subharmonic oscillation ▪ Built-in Auto Standby function

STR-W605xS Applications

* For switching power supplies used in:
* White goods
* Consumer electronics
* Office automation
* Industrial equipment
* Communication equipment Package: 6-Pin fully molded TO-220F-6L (FM207) http://www. DataSheet4U. net/ Not to scale Typical Application VAC

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: STR-W605xS, STRW605xS. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3
