RL103G, RL101G GLASS PASSIVATED SILICON RECTIFIER

RL103G Description

RL101G-RL107G Technical Data Data Sheet N0556, Rev.A RL101G THRU RL107G GLASS PASSIVATED SILICON RECTIFIER Reverse Voltage - 50 to 1000 Volts Forw.

RL103G Features

* A-405
* The plastic package carries Underwriters Laboratory Flammability Classification 94V-0
* Construction utilizes void-free molded plastic technique
* Low reverse leakage
* High forward surge current capability
* High temperature soldering guaranteed: 250°C/10 seconds, 0.37

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: RL103G, RL101G. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
RL103G, RL101G
Manufacturer
SangdeSTMicroelectronics ↗
File Size
318.91 KB
Datasheet
RL101G-SangdestMicroelectronics.pdf
Description
GLASS PASSIVATED SILICON RECTIFIER
Note
This datasheet PDF includes multiple part numbers: RL103G, RL101G.
Please refer to the document for exact specifications by model.
