STGF10NC60HD, STGB10NC60HD - very fast IGBT

STGF10NC60HD Description

STGB10NC60HD - STGD10NC60HD STGF10NC60HD - STGP10NC60HD 600 V - 10 A - very fast IGBT .
This IGBT utilizes the advanced PowerMESH™ process resulting in an excellent trade-off between switching performance and low on-state behavior.

STGF10NC60HD Features

* Low on-voltage drop (VCE(sat))
* Low CRES / CIES ratio (no cross-conduction susceptibility)

STGF10NC60HD Applications

* High frequency motor controls
* SMPS and PFC in both hard switch and resonant topologies

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: STGF10NC60HD, STGB10NC60HD. Please refer to the document for exact specifications by model.
