STPS15L30CB - Low drop power Schottky rectifier

Description

Dual center tab Schottky rectifier suited for switched mode power supply and high frequency DC to DC converters.

Packaged in DPAK, this device is intended for use in low voltage, high frequency inverters, freewheeling and polarity protection applications.

Table 1.

Features

  • Very small conduction losses.
  • Negligible switching losses.
  • Extremely fast switching.
  • Low forward voltage drop.
  • Low capacitance.
  • Low thermal resistance.
  • Avalanche specification.

📥 Download Datasheet

Datasheet preview – STPS15L30CB

Datasheet Details

Part number STPS15L30CB
Manufacturer STMicroelectronics
File Size 226.41 KB
Description Low drop power Schottky rectifier
Datasheet download datasheet STPS15L30CB Datasheet
