AM29PL320D 32 Megabit (2 M x 16-Bit/1 M x 32-Bit) CMOS 3.0 Volt-only High Performance Page Mode Flash Memory

AM29PL320D Description

m o Am29PL320D c Data Sheet w w This product has been retired and is not recommended for designs.For new and current designs, S29GL032M supersedes.
The Am29PL320D is a 32 Mbit, 3.

AM29PL320D Features

* 32 Mbit Page Mode device
* Word (16-bit) or double word (32-bit) mode selectable via WORD# input
* Page size of 8 words/4 double words: Fast page read access from random locations within the page
* Single power supply operation
* Full voltage range: 2.7 to 3.6 volt

AM29PL320D Applications

* Regulated voltage range: 3.0 to 3.6 volt read and write operations and for compatibility with high performance 3.3 volt microprocessors
* Flexible sector architecture
* Sector sizes (x16 configuration): One 16 Kword, two 8 Kword, one 96 Kword and fifteen 128 Kword sectors

📥 Download Datasheet

Preview of AM29PL320D PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
AM29PL320D
Manufacturer
SPANSION
File Size
0.95 MB
Datasheet
AM29PL320D_SPANSION.pdf
Description
32 Megabit (2 M x 16-Bit/1 M x 32-Bit) CMOS 3.0 Volt-only High Performance Page Mode Flash Memory
