VXR22 - Direct Operated 3 Port Solenoid Valve

Product Overview

SMC

Part number	VXR22
Manufacturer	SMC
File Size	3.01 MB
Description	Direct Operated 3 Port Solenoid Valve
Datasheet	VXR22 Datasheet
Note	This datasheet PDF includes multiple part numbers: VXR22, VXR21. Please refer to the document for exact specifications by model.
Additional preview pages of the VXR22 datasheet.

Pilot Operated 2 Port Pilot Operated 2 Port for Zero Differential Pressure Direct Operated 2 Port For Air, Vacuum, Water, Steam, Oil VXD21/22/23 For Air, Water, Oil VXZ22/23 For Air, Vacuum, Water, Oil Valve type N. C. /N. O. Port size 1/8 to 1/2 Orifice size mmø 2 to 10 Valve type N. C. /N. O. Port size 1/4 to 1 32 A to 50 A Orifice size mmø 10 to 50 Valve type N. C. /N. O. Port size 1/4 to 1 Orifice size mmø 10 to 25 Pilot Operated 2 Port VXP21/22/23 For Steam (Air, Water, Oil) Water Ham.
