LM2035 - 5x7 Matrix Display

Name: LM2035
SKU: LM2035-505914

Rohm

The LM2035 by Rohm is a 5x7 Matrix Display. Below is the official datasheet preview.

Datasheet Details

Part number	LM2035
Manufacturer	ROHM
File Size	100.69 KB
Description	5x7 Matrix Display
Datasheet	LM2035_Rohm.pdf
Additional preview pages of the LM2035 datasheet.

1) 5 x 7 dot matrix Circular emitters 2) External dimensions : 17378 x 12.7 x 4.2 mm 3) Emitters : Circular, 2.0mm diameter 4) Black package Dual color type 12.7 2.0 P2.54 5=12.7 17.78 2.54 1/3 LM-2035 Series LED displays !Pin assignments Pin No.1 Pin No.12 Pin No.1 Pin No.7 Pin No.12 Pin No.6 Pin No.7 Pin No.6 Pin No.11 Pin No.17 Dual color type Single color type !Internal circuit schematic Pin No. 12 11 2 9 4 5 6 Pin No. 12 13 14 9 4 5 6 Pin No. 1 3 10 7 8 Pin No. 1 3 7 2 11.
