Transistors 2SA1812 / 2SA1727 / 2SA1776 High-voltage Switching Transistor ( 400V, 0.5A) 2SA1812 / 2SA1727 / 2SA1776 .

A1776 Features

* 1) High breakdown voltage, BVCEO= 400V. 2) Low saturation voltage, typically VCE (sat) = 0.3V at IC / IB = 3) High switching speed, typically tf : 1 s at IC = 100mA. 4) Wide SOA (safe operating area). 100mA / 10mA. Absolute maximum ratings (Ta=25°C) Parameter Collector-base voltage Collector-emi

📥 Download Datasheet

Preview of A1776 PDF
