ISL3150E - RS-485/RS-422 Transceivers

Renesas

📥 Download Datasheet

ISL3150E Datasheet Preview — Preview of ISL3150E PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	ISL3150E
Manufacturer	Renesas
File Size	1.51 MB
Description	RS-485/RS-422 Transceivers
Datasheet	ISL3150E-Renesas.pdf

ISL3150E Product details

Description

. . .

Features

high output drive and high ESD protection, withstanding ±16.5kV IEC61000-4-2 ESD strikes. The large output voltage of 3.1V typical into a 54Ω load provides high noise immunity, and enables the drive of up to 8000ft long bus segments, or eight 120Ω terminations in a star topology. These devices possess less than 125µA bus input currents, thus constituting a true 1/8 unit load. The high output drive combined with the low bus input currents allows for connecting up to 512 transceivers on the same b.
