HD74ACT112, HD74AC112 Dual JK Negative Edge-Triggered Flip-Flop

HD74ACT112 Description

HD74AC112/HD74ACT112 Dual JK Negative Edge-Triggered Flip-Flop REJ03D0244 *0200Z (Previous ADE-205-364 (Z)) Rev.2.00 Jul.16.2004 .
The HD74AC112/HD74ACT112 features individual J, K, Clock and asynchronous Set and Clear inputs to each flipflop.

HD74ACT112 Features

* individual J, K, Clock and asynchronous Set and Clear inputs to each flipflop. When the clock goes High, the inputs are enabled and data will be accepted. The logic level of the J and K inputs may change when the clock is High and the bistable will perform according to the Truth Table as long as min

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: HD74ACT112, HD74AC112. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3
