EL5211T - 60MHz Rail-to-Rail Input-Output Operational Amplifier

Product Overview

Renesas

Datasheet Details

Part number	EL5211T
Manufacturer	Renesas
File Size	841.45 KB
Description	60MHz Rail-to-Rail Input-Output Operational Amplifier
Datasheet	EL5211T Datasheet
Additional preview pages of the EL5211T datasheet.

Product details

Description

PIN NUMBER (HMSOP, DFN) 1 2 3 4 5 6 7 8 Pad PIN NAME VOUTA VINAVINA+ VSVINB+ VINBVOUTB VS+ PD FUNCTION EQUIVALENT CIRCUIT Amplifier A output (Reference Circuit 1) Amplifier A inverting input (Reference Circuit 2) Amplifier A non-inverting input (Reference Circuit 2) Negative power supply Amplifier B non-inverting input (Reference Circuit 2) Amplifier B inverting input (Reference Circuit 2) Amplifier B output (Reference Circuit 1) Positive power supply Functions as a heat sink

Features

a high slew rate of 100V/µs, and fast settling time. Also, the device provides common mode input capability beyond the supply rails, rail-to-rail output capability, and a bandwidth of 60MHz (-3dB). This enables the amplifiers to offer maximum dynamic range at any supply voltage. These features make the EL5211T an ideal amplifier solution for use in TFT-LCD panels as a VCOM driver or static gamma buffer, and in high speed filtering and signal conditioning.
