DTC115TKA - NPN 100mA 50V Digital Transistors

Download the DTC115TKA datasheet PDF (DTC115TE included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for npn 100ma 50v digital transistors.

Features

  • 1) Built-In Biasing Resistor 2) Built-in bias resistors enable the configuration of 　an inverter circuit without connecting external 　input resistors (see inner circuit) . 3) The bias resistors consist of thin-film resistors 　with complete isolation to allow negative biasing 　of the input. They also have the advantage of 　completely eliminating parasitic effects. 4) Only the on/off conditions need to be set 　for operation, making the circuit design easy. 5) Complementary PNP Types: DTA115T serie.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (DTC115TE-Rohm.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number DTC115TKA
Manufacturer ROHM
File Size 1.20 MB
Description NPN 100mA 50V Digital Transistors
Datasheet download datasheet DTC115TKA Datasheet

📁 Similar Datasheet

  • DTC115T - NPN DIGITAL TRANSISTOR (UTC)
  • DTC115TC3 - NPN Digital Transistors (CYStech Electronics)
  • DTC115TE - Digital Transistors (ON Semiconductor)
  • DTC115TM3 - Digital Transistors (ON Semiconductor)
  • DTC115TN3 - NPN Digital Transistors (Cystech Electonics)
  • DTC115TS3 - NPN Digital Transistors (CYStech Electronics)
  • DTC115E - NPN DIGITAL TRANSISTOR (UTC)
  • DTC115EC3 - NPN Digital Transistors (CYStech Electronics)
  • DTC115ECA - NPN Digital Transistors (Kexin)
  • DTC115EE - NPN TRANSISTOR (AiT Semiconductor)
Other Datasheets by ROHM

Full PDF Text Transcription

Click to expand full text
NotNeRewcDoemsimgennsded for DTC115T series NPN 100mA 50V Digital Transistors (Bias Resistor Built-in Transistors) Datasheet Parameter VCEO IC R1 　 Value 50V 100mA 100kΩ 　 lFeatures 1) Built-In Biasing Resistor 2) Built-in bias resistors enable the configuration of 　an inverter circuit without connecting external 　input resistors (see inner circuit) . 3) The bias resistors consist of thin-film resistors 　with complete isolation to allow negative biasing 　of the input. They also have the advantage of 　completely eliminating parasitic effects. 4) Only the on/off conditions need to be set 　for operation, making the circuit design easy. 5) Complementary PNP Types: DTA115T series 6) Lead Free/RoHS Compliant.
