SF2067B 172.8 MHz
SAW Filter
• • • •
Low Insertion Loss 5.0 X 7.0 mm Surface-Mount Case 50Ω Single Ended Input 200Ω Balanced Output Complies with Directive 2002/95/EC (RoHS)
Pb
Absolute Maximum Ratings
Rating Maximum Incident Power in Passband Max. DC voltage between any 2 terminals Storage Temperature Range Max Soldering Temperature Value +10 30 -40 to +85 265°C for 10 s Units dBm VDC °C
SMP-03
Electrical Characteristics
Characteristic Nominal Frequency Minimum Insertion Attenuation Amplitude Ripple (p-p) Group Delay Ripple (p-p) Group Delay VSWR Phase Ripple (p-p) Pass Bandwidth Adjacent Channel Selectivity Relative Attenuation (relative to αmin) Sym fN αmin ∆α ∆τ τ ∆ϕτ B1.
