PT2313L - 4-Channel Audio Processor

Description

PT2313L is a four-channel digital control audio processor utilizing CMOS Technology.

Volume, Bass, Treble and Balance, Front/Rear Fader Processor are incorporated into a single chip.

Features

  • ! CMOS Technology ! Least External Components ! Treble and Bass Control ! Loudness Function ! 3 Stereo Inputs with Selectable Input Gain ! Input/Output for External Noise Reduction System/Equalizer ! 4 Independent Speaker Controls for Fader and Balance ! Independent Mute Function ! Volume Control in 1.25 dB/step ! Low Distortion ! Low Noise and DC Stepping ! Controlled by I2C Bus Micro-Processor Interface ! Pin-to-pin Compatible with TDA7313.

📥 Download Datasheet

Datasheet Details

Part number PT2313L
Manufacturer Princeton Technology Corp
File Size 181.72 KB
Description 4-Channel Audio Processor
