HY520SBO, HY520SBO_Power OBS SERIES 25 WATT

Power-One

HY520SBO Description

Powering Communications and Technology OBS SERIES 25 WATT .
OBS single output DC/DC converters provide up to 25 Watts of output power in an industry standard package and footprint.

HY520SBO Features

* Industry standard package
* 24 and 48V input versions
* 25W output power
* 100°C baseplate operation
* TECHNICAL SPECIFICATIONS Input Voltage Range 24 VDC Nominal 48 VDC Nominal Reflected Ripple Input Reverse Voltage Protection

HY520SBO Applications

* These units are 100% surface-mount construction and fully compatible with production board washing processes. Trim And Enable Pins Fixed Frequency 1500V Isolation 6-Sided Shielding EFFICIENCY % Efficiency vs. Load (24V Input) 95 90 85 80 EFF. OBS025YG 75 70 65 10 20 30 40 50 60 70 80 90 100 LO AD

📥 Download Datasheet

HY520SBO Datasheet Preview — This datasheet PDF includes multiple part numbers: HY520SBO, HY520SBO_Power. Please refer to the document for exact specifications by model.

Datasheet Details

Part number: HY520SBO, HY520SBO_Power
Manufacturer: Power-One
File Size: 314.75 KB
Datasheet: HY520SBO_Power-One.pdf
Description: OBS SERIES 25 WATT
Note: This datasheet PDF includes multiple part numbers: HY520SBO, HY520SBO_Power.
Please refer to the document for exact specifications by model.
