BULD50SL Datasheet (Power Innovations Limited)

BULD50SL, NPN Transistor

The new BULDxx range of transistors have been designed specifically for use in High Frequency Electronic Ballasts (HFEB’s).

This range of switching transistors has tightly controlled storage times and an integrated fast trr antiparallel diode.

The revolutionary design ensures that the diode has both

BULD50KC, BULD50SL NPN SILICON TRANSISTOR WITH INTEGRATED DIODE Copyright © 1997, Power Innovations Limited, UK FEBRUARY 1994 - REVISED SEPTEMBER 1997 q Designed Specifically for High Frequency Electronic Ballasts Integrated Fast trr Anti-Parallel Diode, Enhancing Reliability Diode trr Typically 1 µs New Low-Height SL Power Package, TO220 Pin-Compatible Tightly Controlled Transistor Storage Times Voltage Matched Integrated Transistor and Diode Characteristics Optimised for Cool Running Diode-T

BULD50SL Features

* is single-in-line package consists of a circuit mounted
