PI5C32390 - 16-to-8 Multiplexer/Demultiplexer Bus Switch

Download the PI5C32390 datasheet PDF (PI5C3390 included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for 16-to-8 multiplexer/demultiplexer bus switch.

Description

Pericom Semiconductor’s PI5C3390 and PI5C32390 are 16-to-8 multiplexer/demultiplexer bus switches with a low On-Resistance allowing inputs to be connected directly to outputs.

The two enable inputs connect each of eight I/O to the common I/O pin.

Features

  • Near-Zero propagation delay.
  • Low noise, 25-ohm version (PI5C32390).
  • 5-ohm switches connect inputs to outputs (PI5C3390).
  • Direct bus connection when switches are ON.
  • Ultra-low quiescent power (0.2µA typical).
  • Ideally suited for notebook.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (PI5C3390_PericomSemiconductorCorporation.pdf) that lists specifications for multiple related part numbers.
