PI74ALVCH16244 - 16-Bit Buffer Driver with 3-State Outputs

Pericom Semiconductor Corporation

Datasheet Details

Part number	PI74ALVCH16244
Manufacturer	Pericom Semiconductor Corporation
File Size	130.84 KB
Description	16-Bit Buffer Driver with 3-State Outputs
Datasheet	PI74ALVCH16244_PericomSemiconductorCorporation.pdf

Pericom Semiconductor’s PI74ALVCH16244 is an non-inverting 16-bit buffer/driver designed for low-voltage 2.3V to 3.6V VCC operation.

Designed for low-voltage operation VCC = 2.3V to 3.6V Hysteresis on all inputs Typical VOLP (Output Ground Bounce) < 0.8V at VCC = 3.3V, TA = 25°C Typical VOHV (Output VOH Undershoot) < 2.0V at VCC = 3.3V, TA = 25°C Bus Hold retains last active bus state during 3-State, eliminating the need for external pullup resistors Industrial operation at.
40°C to +85°C Packaging:.
48-pin 240-mil wide plastic TS.
