ETQP3M100KVP - Power Inductors

Panasonic

ETQP3M100KVP Description

Power Inductors Power Choke Coil (Automotive Grade) Series: PCC-M0530M-LP(MC) PCC-M0630M-LP(MC) PCC-M0840M-LP(MC) PCC-M1040M-LP(MC) High heat resist.

ETQP3M100KVP Features

* High heat resistance : Operation up to 155 °C including self-heating
* Fig.1 Inductance v. s. DC current
* Low proﬁle : 3 mm max. height (PCC-M0530M-LP, PCC-M0630M-LP) 4 mm max. height (PCC-M0840M-LP, PCC-M1040M-LP) ETQP4M4R7KVC(reference) 5
* SMD type
* High-reliability

ETQP3M100KVP Applications

* 2
* High bias current : Excellent inductance stability using ferrous alloy magnetic material (Fig.1) 1
* Temp. stability : Excellent inductance stability over broad temp. range
* Low audible (buzz) noise : A gapless structure achieved with metal composite core 0 0 5 10 15 20 25

📥 Download Datasheet

ETQP3M100KVP Datasheet Preview — Preview of ETQP3M100KVP PDF

Datasheet Details

Part number: ETQP3M100KVP
Manufacturer: Panasonic
File Size: 205.60 KB
Datasheet: ETQP3M100KVP-Panasonic.pdf
Description: Power Inductors
