AQW214S, AQW212S - Photo MOS Relay

AQW214S Description

Miniature SOP8-pin type of 60V/350V/400V load voltage GU SOP 2 Form A (AQW21❍S) 9.37 .369 1 2 3 4 4.4 .173 2.1 .083 mm inch 8 7 6 5 RoHS complia.

AQW214S Features

* 1. 2 channels in miniature SOP8-pin design The device comes in a super-miniature SO package measuring (W) 4.4 × (L) 9.37 × (H) 2.1 mm (W) .173× (L) .369× (H) .083 inch
* approx. 38% of the volume and 66% of the footprint size of DIP8-pin type. 2. Controls low-level analog signals PhotoMOS fea

AQW214S Applications

* Measuring instruments
* Data communications
* Computers
* Industrial robots TYPES Output rating
* Load voltage Load current Package Tube packing style AC/DC dual use 60V 350V 400V 400mA 100mA 80mA SOP8-pin AQW212S AQW210S AQW214S
* Indicate the pea

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: AQW214S, AQW212S. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
AQW214S, AQW212S
Manufacturer
Panasonic
File Size
142.23 KB
Datasheet
AQW212S-Panasonic.pdf
Description
Photo MOS Relay
Note
This datasheet PDF includes multiple part numbers: AQW214S, AQW212S.
Please refer to the document for exact specifications by model.
