AN6108SA - Digital Communication IF Amplifier IC

Datasheet Summary

Description

Pin No.

1 2 3 4 5 6 7 8 MIX-IN MIX-DEC GND-MIX LO-IN RSSI-OUT OP-NEG OP-OUT OP-POS/SLEEP Description Pin No.

Features

  • s Block Diagram LIM-OUT 16 15 MIX VCC 14 13 12 11 IF VCC 10 IF GND 9 MIX GND 1 2 3 4 5 6 7 8 MIX-IN VLO RSSI-OUT VCC +.
  • RSSI.

📥 Download Datasheet

Datasheet preview – AN6108SA

Datasheet Details

Part number AN6108SA
Manufacturer Panasonic Semiconductor
File Size 148.35 KB
Description Digital Communication IF Amplifier IC
Datasheet download datasheet AN6108SA Datasheet
Additional preview pages of the AN6108SA datasheet.

📁 Similar Datasheet

  • AN610P - Balance Modulator Circuit (Panasonic)
  • AN611 - TD-SCDMA Radio Chipset Block Diagram for Handset Application (Maxim Integrated Products)
  • AN611 - TD-SCDMA Radio Chipset Block Diagram for Handset Application (Maxim Integrated Products)
  • AN6130N - FM Noise Canceller Circuit (Panasonic)
  • AN6136 - (AN6135) Hi-Fi Pop-Noise Canceller Circuit (Matsushita)
  • AN614 - A SIMPLE ALTERNATIVE TO ANALOG ISOLATION AMPLIFIERS (Silicon Laboratories)
  • AN616 - Video Signal Processing Circuit (Panasonic)
  • AN6162SC - Narrow Band FM Receiver Circuit (Panasonic)
  • AN6164 - Constant Voltage Drive Speech Network Circuits (Panasonic)
  • AN6166NK - Cordless Telephone Speech Network IC (Panasonic)
Other Datasheets by Panasonic Semiconductor
  • AN6107 - Digital Communication IF Amplifier IC
  • AN6107SA - Digital Communication IF Amplifier IC
  • AN612 - Balance Modulator Circuit
  • AN6123MS - Speech network IC with ALC
  • AN6135 - (AN6135 / AN6136) HI-FI POP-NISE CANCELLER CIRCUIT
  • AN6136 - (AN6135 / AN6136) HI-FI POP-NISE CANCELLER CIRCUIT
  • AN614 - Video amplifier/ modulator/demodulator IC
  • AN6150 - Speech Network Circuit

Full PDF Text Transcription

Click to expand full text
AN6107SA (under development) Digital Communication IF Amplifier IC s Overview The AN6107SA is an IF amplifier IC for digital cellular telephones. It supports mixer input frequencies up to 150 MHz, featuring low current consumption. 5.00±0.20 16 9 Unit : mm 4.40±0.20 1 8 (0.225) 0.22 +0.10 – 0.05 0.65 SEATING PLANE • Operating supply voltage range : 2.7 to 4 V • Current consumption : Typ 3.9 mA during operation, 10 µA or less at sleep • RSSI input D range : 80 dB • Built-in operational amplifier. • Package : SSOP016-P-0225A with 0.65 mm pitch 1.20±0.2 SOP package with 16 pins (SSOP016-P-0225A) s Pin Descriptions Pin No. 1 2 3 4 5 6 7 8 MIX-IN MIX-DEC GND-MIX LO-IN RSSI-OUT OP-NEG OP-OUT OP-POS/SLEEP Description Pin No.
