Allowing supply with the radial taping
6.9±0.1
0.15
0.7
4.0
1.05 2.5±0.1 (1.45) ±0.05 0.8
0.65 max. 1.0
0.45.
0.05
+0.1
I Absolute Maximum Ratings Ta = 25°C
Parameter Collector to base voltage Collector to emitter voltage Emitter to base voltage Peak collector current Collector current Collector power dissipation Junction temperature Storage temperature Symbol VCBO VCEO VEBO ICP IC PC Tj Tstg Rating.
The following content is an automatically extracted verbatim text
from the original manufacturer datasheet and is provided for reference purposes only.
View original datasheet text
Transistors
2SB1320A
Silicon PNP epitaxial planer type
Unit: mm
For general amplification Complementary to 2SD1991A I Features
• High forward current transfer ratio hFE • Allowing supply with the radial taping
6.9±0.1
0.15
0.7
4.0
1.05 2.5±0.1 (1.45) ±0.05 0.8
0.65 max.
1.0
0.45−0.05
+0.1
I Absolute Maximum Ratings Ta = 25°C
Parameter Collector to base voltage Collector to emitter voltage Emitter to base voltage Peak collector current Collector current Collector power dissipation Junction temperature Storage temperature Symbol VCBO VCEO VEBO ICP IC PC Tj Tstg Rating −60 −50 −7 −200 −100 400 150 −55 to +150 Unit V V V mA mA mW °C °C
1
2
3
0.45−0.05
2.5±0.5
2.5±0.5
+0.
2SB1320 Datasheet
