1N4728A

The 1N4728A is GLASS PASSIVATED JUNCTION SILICON ZENER DIODE designed by Pan Jit International.

Product Overview

Pan Jit International

Part number	1N4728A
Manufacturer	Pan Jit International
File Size	385.59 KB
Description	GLASS PASSIVATED JUNCTION SILICON ZENER DIODE
Datasheet	1N4728A-PanJitInternational.pdf
Additional preview pages of the 1N4728A datasheet.

Low profile package.
Built-in strain relief.
Low inductance.
High temperature soldering : 260°C /10 seconds at terminals.
Plastic package has Underwriters Laboratory Flammability Classification 94V-O.
Both normal and Pb free product are available : Normal : 80~95% Sn, 5~20% Pb Pb free: 98.5% Sn above DO-41/DO-41G 1.0(25.4)MIN. Unit: inch(mm) .034(.86) .028(.71) .205(5.2) .160(4.1).
