SN74LS367A, SN74LS365A Datasheet - ON Semiconductor

SN74LS367A 3-State Hex Buffer

SN74LS365A, SN74LS367A, SN74LS368A 3 State Hex Buffers These devices are high speed hex buffers with 3-state outputs. They are organized as single 6-bit or 2-bit/4-bit, with inverting or non-inverting data (D) paths. The outputs are designed to drive 15 TTL Unit Loads or 60 Low Power Schottky loads when the Enable (E) is LOW. When the Output Enable (E) is HIGH, the outputs are forced to a high impedance “off” state. If the outputs of the 3-state devices are tied together, all but one de.

SN74LS365A_ONSemiconductor.pdf

This datasheet PDF includes multiple part numbers: SN74LS367A, SN74LS365A. Please refer to the document for exact specifications by model.
SN74LS367A Datasheet Preview Page 2 SN74LS367A Datasheet Preview Page 3

Datasheet Details

Part number:

SN74LS367A, SN74LS365A

Manufacturer:

ON Semiconductor ↗

File Size:

131.79 KB

Description:

3-state hex buffer.

Note:

This datasheet PDF includes multiple part numbers: SN74LS367A, SN74LS365A.
Please refer to the document for exact specifications by model.
