NUC2401MN, Integrated Common Mode Choke

The NUC2401MN is an Integrated Common Mode Filter for the elimination of common mode noise in high speed data line applications such as IEEE1394, USB2.0 and other LVDS type applications.

ESD protection is integrated into the Common mode filter for superior protection and significant part count redu

NUC2401MN Features

* http://onsemi.com SIMPLIFIED SCHEMATIC VCC 6

* Common mode EMI Filtering and ESD Protection Integration of 5 Discrete components ±12 kV ESD Protection per IEC61000

* 4

* 2 (Contact Discharge) DFN: 2.0 x 2.2 mm Package
