MURA140, MURA130 Surface Mount Ultrafast Power Rectifiers

ON Semiconductor

Description

Power Rectifier, Ultra-Fast Recovery, 1 A, 300-400 V MURA130, SURA8130, MURA140, NRVUA140V, SURA8140 Ideally suited for high voltage, high frequency r.

📥 Download Datasheet

MURA140 Datasheet Preview — This datasheet PDF includes multiple part numbers: MURA140, MURA130. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: MURA140, MURA130
Manufacturer: ON Semiconductor ↗
File Size: 165.14 KB
Datasheet: MURA130-ONSemiconductor.pdf
Description: Surface Mount Ultrafast Power Rectifiers
Note: This datasheet PDF includes multiple part numbers: MURA140, MURA130.
Please refer to the document for exact specifications by model.

Features

* Small Compact Surface Mountable Package with J
* Bend Leads
* Rectangular Package for Automated Handling
* High Temperature Glass Passivated Junction
* Low Forward Voltage Drop (0.89 V Max @ 1.0 A, TJ = 150C)
* NRVUA and SURA8 Prefixes for Automotive and Other Applicatio
