MC14046B - Phase Locked Loop

Product Overview

ON Semiconductor

📥 Download Datasheet

MC14046B Phase Locked Loop by ON Semiconductor - Datasheet Preview — Datasheet preview – MC14046B

Datasheet Details

Part number	MC14046B
Manufacturer	ON Semiconductor
File Size	214.16 KB
Description	Phase Locked Loop
Datasheet	MC14046B Datasheet
Additional preview pages of the MC14046B datasheet.

Product details

Features

Buffered Outputs Compatible with Low.
Power TTL.
Diode Protection on All Inputs.
Supply Voltage Range = 3.0 to 18 V.
Pin.
for.
Pin Replacement for CD4046B.
Phase Comparator 1 is an Exclusive OR Gate and is Duty Cycle Limited.
Phase Comparator 2 Switches on Rising Edges and is not Duty Cycle Limited.
NLV Prefix for Automotive and Other.
